3W 220V AC Torque Motor with Gearbox
2 Customer Reviews
Torque Motor Features
- 3W power, rated speed of 1350 rpm, single phase 110V/220V AC voltage.
- Depending on the strong beginning torque and slope properties, the speed might vary greatly.
- There are 3, 5, 6, 9...200 different gear ratios to choose from.
- The motor torque varies in proportion to the square of the voltage.
Specification
| Motor Type | Torque Motor |
| Phase | 1 |
| Voltage (V) | 110 |
| Shaft Type | Pinion Shaft |
| Starting Torque(mN.m) | 69 |
| Max. Output Power | 3.2W |
| Torque at Max. Output Power | 41 mN.m at 50Hz, 37 mN.m at 60Hz |
| Weight | Motor: 0.75 kg, Gear box: 0.4 kg |
